Local dimming display power

Model: SHG5028A-248E Input Voltage: 176-264Vac Rated Power: 164W Peak Power: 190W Input Voltage Range: 176-264Vac Output Voltage & Current: 12V/3.5A; 18V/1.4A; 24~25.6~28V, 121.5mA, 270mA (10% APL) *28CH Output Frequency: DC Output Waveform: DC Operating Efficiency: 88% at rated load Dimensions: 202(L) × 164(W) × 14(H) mm Weight: 0.48Kg Operating Temperature: 0~55℃

OLED32 display power supply

Model: SHLD3201F-237E Input Voltage: 100-240Vac Rated Power: 270W Peak Power: 306W Input Voltage Range: 90-264Vac Output Voltage & Current: 21.5V/12.56A Output Frequency: DC Output Waveform: DC Operating Efficiency: 88% at rated load Dimensions: 190(L) × 120(W) × 31(H) mm Weight: 0.628Kg Operating Temperature: 0~55℃

360W module power supply

Model: SHD3601F-307E Input Voltage: 350-800Vdc Rated Power: 360W Peak Power: 400W Input Voltage Range: 300-850Vdc Output Voltage & Current: 24V/15A Output Frequency: DC Output Waveform: DC Operating Efficiency: 86% at rated load Dimensions: 220(L) × 115.5(W) × 51(H) mm Weight: 0.84Kg Operating Temperature: 0~60℃

TV two-in-one power supply

- Input: 90-264Vac - Output: 1. Power Part: 12.0V/3.0A; 18.5V/2.0A 2. LED Part: 84V~95.2V/400mA *4CH - Standby power consumption: Less than 0.2W @240Vac - Efficiency: ≥85% - PF Value: ≥0.99 Model: SHG7504D-101H Product Dimensions: 220*170*14mm Certifications: RoHS, CCC, UL, VDE

TV built-in power supply

- Input: 90-264Vac - Output: 1. Power Part: 12.5V/5A, 18.5V/2A 2. LED Part: 11.2V-12.5V/25A - Standby power consumption: Less than 0.2W @ 240Vac - Efficiency: ≥ 86% - PF Value: ≥ 0.99 Model: SHLD8601F-101H Product Dimensions: 280*210*14mm Certifications: RoHS, CCC, UL, VDE

Display power supply

• Input: 176-264Vac • Output: 12V /3.5A, 18V/1.6A, Backlight 119V/550mA/2CH • Standby power consumption is less than 0.5W (12V@20mA) Model: SHG6502A-248E Product size: 162*288*13.5mm

Display power supply

• Input: 96-144Vac • Output: 12V 4A, Backlight 130V/400mA/2CH • Standby power consumption is less than 0.5W (12V@20mA) Model: SHG6502C-116E Product size: 154*312*13.5mm

Display power supply

• Input: 90-264Vac • Output: 12V 5A Backlight 67.4V/600mA/1CH • Standby power consumption is less than 0.5W (12V@20mA) Model: SHG4001A-173E Product size: 180*163*15mm

Smart toilet seat power supply

• Input: 100-240Vac • Output: 24V/4.5A, 12V/1.5A, 5V/1A • Average efficiency ≥ 85% Model: SHD0961F-255S (Main Control Board) Product size: 280*71mm Certifications/Certificates met: • Compliant with GB4943-1:2011 • Compliant with GB9254-2008 Class B, EN 55032 CLASS B • RoHS

Printer power supply

• Input: 90Vac-110Vac • Output DC: 25.7V/0.9A • Standby power consumption is less than 0.5W • Efficiency ≧ 82% Model: SAWA-80-117257A Product dimensions: 95*51*58mm Compliant certification/certificate: PSE

Printer power supply

• Input: 90Vac-264Vac • Output DC: 24V/3A & 8V 0.1A 72W • Standby power consumption is less than 0.2W • Efficiency ≧ 80% Model: SHD0901F-235S Product size: 176*90*35mm Conforming certification/certificate: CB CQC

Printer high voltage power supply

• Input: 24VDC, PWM control signal • Output high voltage: +1100V/+9.5uA, -1160V/-10uA, -300V/-5uA, -400V/-8uA Model: SHD0304D-204S Product size: 90*120*19mm
